MODEL |
ZFH-66C |
|
FUNCTION |
Auto bending/cutting/bridge/ |
|
Rule thickess |
0.71 1.05 1.42 |
|
Rule size |
0.71*23.8-60mm 1.42*23.8-26.1 1.05*30-60mm |
|
Motor and driver |
Panassonic |
|
Bridge width |
5-10mm(optional) |
|
Power |
220/380v 50hz/60hz |
|
Maximum angle |
120 |
|
Minimum bending |
1mm |
|
Minimum cut size |
0.5mm |
|
File format Supported |
dxf |
|
power |
2.2kw |
|
Presure |
6kg |
|
power |
3kw |
|
Machine packing size |
2260*810*1360 |
|
MODEL |
ZFS-66C
|
|
FUNCTION: |
Auto bending/cutting/bridge/lipping /nicking /perforation |
|
Rule thickess |
0,71/1.05mm |
|
Rule height |
8-30mm |
|
Bridge hight |
18-21mm |
|
Motor and driver |
Panassonic |
|
Bridge width |
5-10mm(optional) |
|
Power: |
220/380v 50hz/60hz |
|
Maximum angle |
120 |
|
Minimum bending |
1mm |
|
Minimum cut size |
0.5mm |
|
File format Supported |
dxf |
|
power |
2.2kw |
|
Presure |
6kg |
|
power |
3kw |
|
Machine packing size |
2300*880*1600 |
|
MODEL |
ZFS-66CBN |
|
FUNCTION: |
Auto bending/cutting/bridge/lipping /broaching /nicking /perforation |
|
Rule thickess |
0,71/1.05mm |
|
Rule height |
8-30mm |
|
Bridge hight |
18-21mm |
|
Motor and driver |
Panassonic |
|
Bridge width |
5-10mm(optional) |
|
Power: |
220/380v 50hz/60hz |
|
Maximum angle |
120 |
|
Minimum bending |
1mm |
|
Minimum cut size |
0.5mm |
|
File format Supported |
dxf |
|
power |
2.2kw |
|
Presure |
6kg |
|
power |
3kw |
|
Machine packing size |
2300*880*1600 |
